Beschrijving
| Load capacity | 1000 kg |
| Lifting speed at 50 Hz | 8m / min |
| Operating voltage | 400V 50 Hz – 24Vdc |
| Protection Class | IP 55 DIN 40050 |
| Motor power at 50 Hz | 1,5 kW |
| FEM Class | 2m |
| DC braking system | 2 brakes |
| Noise level | <67.5 dB (full load) |
| Loading wheel | 5 pockets |
| RUD® Load chain | 8×24 mm |
| Number of chains | 1 |
| Chain weight | 1.4 kg / m |
| Weight of the body | 54 kg |
| Type of control | 24V Low voltage control |
| Type of connector | 400V EEC 16A – 3P + PE / XLR3 connector |
| Climbing use | Permitted |
| Safety factor | 8: 1 |
| Load cell | Included |
| Stromag ® Limit Switch with 4 switches | Included |
| Encoder | Optional |
| Inverter | Recommended |
Can be used with Touring PRO or Easy Touch control system.
