Beschrijving
| Load capacity | 250 kg |
| Lifting speed at 50 Hz | 16m / min |
| Operating voltage | 400V (3ph) / 230V (1ph) 50 Hz – 24Vdc |
| Protection Class | IP 55 DIN 40050 |
| Motor power at 50 Hz | 0.75 kW |
| FEM Class | 2m |
| DC braking system | 2 brakes |
| Noise level | <67.5 dB (full load) |
| Loading wheel | 5 pockets |
| RUD® Load chain | 6,3×19 mm |
| Number of chains | 1 |
| Chain weight | 0.86 kg / m |
| Weight of the body | 35 kg |
| Type of control | 24V Low voltage control |
| Type of connector | 400V EEC 16A – 3P + PE / 230 EEC 16A – 2P + PE XLR3/XLR5 connector |
| Climbing use | permitted |
| Safety factor | 10:1 |
| Load cell | Included |
| Stromag ® Limit Switch with 4 switches | Included |
| Encoder | Optional |
| Inverter | Included |
Can be used with Touring PRO or Easy Touch control system.
